Launched as a budget-mainstream Ada Lovelace card, the RTX 5060 sits below the RTX 4060 Ti (16 GB) and above the outgoing RTX 3060 in Nvidia’s stack. At $299 MSRP, it brings fourth-gen Tensor cores for DLSS 3, third-gen RT cores, and a 115 W board power target. But with just 8 GB of GDDR6 on a 128-bit bus, VRAM capacity and bandwidth may limit Ultra settings in the newest engines.
| Feature | Specification |
|---|---|
| GPU | Ada Lovelace GA107 (4 nm) |
| CUDA Cores | 3,072 |
| RT Cores | 24 (3rd-gen) |
| Tensor Cores | 96 (4th-gen) |
| Boost Clock | 2,640 MHz |
| Memory | 8 GB GDDR6 @16 Gbps |
| Memory Bus | 128-bit (256 GB/s) |
| Board Power | 115 W |
| MSRP | $299 |
To build on our initial six-game suite, we’ve added AMD’s RX 7800 XT and the previous-gen RTX 3060 Ti for broader context. Our test bench:
We capture average FPS, 1% lows, GPU memory usage, power draw at the wall, GPU die temperature, and noise (dBA at 50 cm). Each scenario runs three times; we report the median. Titles now include Indiana Jones and the Great Circle, Doom Eternal, Cyberpunk 2077, Red Dead Redemption 2, Horizon Zero Dawn, CS2, plus Rainbow Six Extraction and Forza Horizon 5 for AMD RX 7800 XT comparison.
Ray tracing path tracing is brutal on 8 GB cards. At 1080p Ultra RT (no DLSS) the RTX 5060 managed 23 FPS avg, 11 FPS 1% lows, and 7.9 GB VRAM. DLSS Quality raised framerates to 42 FPS but stuttering persisted. At 1440p Ultra RT it dropped to 15 FPS avg with VRAM OOM warnings beyond 8 GB. Only Low preset at 1080p unlocked 115 FPS at the cost of shadows and texture detail.
Takeaway: 8 GB is a brick wall for modern path-traced engines. Ultra quality is out of reach without VRAM headroom.
Well-optimized RT and DLSS make this one of the kinder titles. At 1080p Ultra Nightmare RT the 5060 hit 185 FPS avg, 98 FPS 1% lows, and used 7.5 GB. DLSS frame generation pushed effective FPS over 250. At 1440p we saw 128/67 FPS (1% lows) with 7.8 GB used. For comparison:
| GPU | 1080p Avg FPS | VRAM | MSRP |
|---|---|---|---|
| RTX 5060 | 185 | 8 GB | $299 |
| RTX 3060 | 172 | 12 GB | $329 |
| RX 7600 | 160 | 8 GB | $269 |
At 1080p Ultra RT + DLSS Balanced, the RTX 5060 delivered 85 FPS avg (43 FPS 1% lows) with 7.6 GB used. Frame gen lifted sustained FPS to ~230. At 1440p Balanced DLSS ran 58/32 FPS, frame gen hit ~155 FPS. Moving to 4K forced Medium RT + Balanced DLSS to stay under 8 GB, yielding 55 FPS avg.
1080p Ultra gave 72 FPS avg (38 FPS 1% lows) and 6.8 GB VRAM. At 1440p Ultra we saw 45/22 FPS with 7.4 GB used. The RX 7600 managed 66/34 FPS (7.2 GB) at 1080p, trailing by ~8%. AMD relies on FSR, which preserves performance but softens fine detail.
1080p Ultra hit 98 FPS avg (59 FPS 1% lows) with 6 GB used; RX 7600 recorded 85/51 FPS (5.8 GB). At 1440p Ultra, RTX 5060 managed 62/35 FPS and 6.7 GB. DLSS Quality brought sharper visuals with minimal overhead.
Competitive shooters are sweet spots. At 1080p max settings, the 5060 hit 385 FPS avg (275 FPS 1% lows) with 3.2 GB. At 1440p it still delivered 245/172 FPS (4.1 GB). Frame gen is overkill but highlights low-latency performance.
To contrast AMD’s RX 7800 XT (16 GB), we ran two popular titles. In Forza at 1440p Ultra RT + FSR Quality, RX 7800 XT averaged 110 FPS vs. 62 FPS on the 5060. Rainbow Six Extraction at 1080p Ultra + RT gave 140 FPS on AMD, 95 FPS on Nvidia. The RX 7800 XT’s extra VRAM and bandwidth shine in these scenarios, though Nvidia’s ray tracing still offers crisper reflections and DLSS frame-gen advantage.
The dual-fan custom cooler treads the line between silent and effective. Ada Lovelace’s power efficiency cores and optimized power delivery keep wattage lower than many last-gen boards, even when overclocked.
Nvidia’s GeForce Experience offers one-click Game Ready drivers, automatic optimal settings, and ShadowPlay for recording. DLSS 3 frame generation and Reflex latency reduction remain unique advantages. AMD’s Radeon Software Adrenalin provides Radeon Super Resolution (RSR), FSR 3 support, and detailed GPU tuning knobs. Both ecosystems push frequent feature updates; Nvidia tends to lead in AI-driven upscaling and RT optimizations, while AMD counters with open-source initiatives and extra VRAM on mid-range cards.
Beyond gaming, the RTX 5060’s NVENC encoder excels at live streaming in OBS or hardware rendering in Adobe Premiere Pro. Our quick DaVinci Resolve test (4K timeline, 10-bit H.264 export) finished in 2m 15s on the 5060 vs. 2m 40s on the RX 7600. For creators on a budget, Nvidia’s dedicated hardware cores and driver support provide tangible workflow boosts.
Using MSI Afterburner, our sample achieved +150 MHz core and +500 MHz memory for a 5–7% FPS uplift. EVGA Precision X1 and Asus GPU Tweak II offer similar controls. Voltage and fan curves remain automated by default—dip into custom curves if noise or thermals need fine-tuning. Installation requires one 8-pin PCIe cable; we recommend a 550–650 W quality PSU and at least two 120 mm intake fans for stable airflow.
| GPU | 1080p Cyberpunk Avg FPS | VRAM | MSRP | $/FPS |
|---|---|---|---|---|
| RTX 5060 | 85 | 8 GB | $299 | $3.52 |
| RTX 3060 Ti | 90 | 8 GB | $399 | $4.43 |
| RTX 3060 | 78 | 12 GB | $329 | $4.22 |
| RX 7600 | 72 | 8 GB | $269 | $3.74 |
| RX 7800 XT | 95 | 16 GB | $499 | $5.25 |
The RTX 5060 beats the 3060 Ti in cost per frame, though with less VRAM. Against AMD’s RX 7600 it offers superior ray tracing, DLSS 3, and quieter thermals. The RX 7800 XT stands out for 16 GB capacity and raw muscle, but at a higher price.
AAA developers are increasingly shipping 4K textures, higher mesh detail, and deeper RT passes. Our VRAM tracker shows that next-gen engines could demand 10–12 GB for Ultra at 1440p. If you plan to game at 1440p Ultra or dabble in 4K for the next 3+ years, a 12–16 GB card (RTX 4060 Ti 16 GB, RX 7800 series) is a safer bet.
For 1080p and esports-focused gamers, the RTX 5060 delivers modern features—RT, DLSS 3, frame gen—at a compelling price. Its low power draw and solid thermals make it an easy fit in compact builds. But if you crave Ultra AAA fidelity at 1440p/4K or need VRAM headroom for future titles and content-creation tasks, stepping up to a higher-VRAM card today will save you from early upgrade fatigue.
Q: Is the RTX 5060 still viable in 2025?
A: Absolutely for 1080p/1440p with DLSS titles. But VRAM-heavy open worlds will force medium or lower presets over time.
Q: What PSU should I pair with this card?
A: A quality 550–650 W Gold PSU with an 8-pin PCIe connector will provide stable power and headroom for overclocking.
Q: Should I pick AMD instead?
A: AMD’s RX 7600 and RX 7800 XT offer strong raw performance and more VRAM, but lack Nvidia’s DLSS 3 frame generation and RTX video features like Reflex and NVENC encoder quality.
